Automatic shut-off fuel nozzle designed for service stations and industrial fueling points, with 0.3-second shut-off, FKM seals, and one-finger flow control.
The GY-11A automatic shut-off fuel nozzle is designed for service-station and industrial fueling applications. Its automatic shut-off mechanism stops fuel flow within 0.3 seconds when fuel reaches the sensing port, helping prevent overfilling and spills. This fuel nozzle is built with FKM seals and an ergonomic hold-open latch, supporting reliable, comfortable operation at flow rates up to 60 L/min.
Product Name | 11A Automatic Fuel Nozzle | Application | Fuel Dispenser Nozzle |
Model Number | GY-11A | Kind | Fuel-servicing Equipment |
Material | Aluminum alloy | nominal pressure | 0.6MPa |
Inlet Size | 3/4 inch | Outlet Size | 13/16” and 15/16” |
Brand Name | DESEINOR | imported vacuum | ≥54kPa |
measuring accuracy | ±0.3% | outlet pressure | ≤0.3MPa |
anti-hazard classification | Ex dmⅡBT4 | Installation Method | Thread connection |
Packing Size | |||
L*W*H(CM) | 41.3*33*36.5 | ||
QTY/CTN | 10PCS/CTN | ||
N.W(KGS) | 12KGS | ||
Swift automatic shut-off: Featuring a high-sensitivity sensing system that stops fuel flow within 0.3 seconds as the fuel reaches the nozzle's sensing point, efficiently preventing overfilling, reducing spill risk, and limiting product loss.
Aluminum body with FKM seals: The high-strength die-cast aluminum body helps dissipate static charge, while the FKM main seals resist fuel, corrosion, and elevated temperatures, supporting leak-resistant operation during prolonged high-pressure service.
Efficient dispensing: With a flow range of 0–60 L/min, the fuel nozzle supports efficient dispensing and helps shorten refueling time.
Comfortable operation: The ergonomic handle allows the lever to be operated with one finger, while the hold-open latch reduces fatigue during extended use.
