30000L Mobile Fuel Station uses double islands, 4 refueling machines, and 8 refueling guns. CPU open protocol, you can contact the IC card management system. The built-in water tank has 2 positions, controlled by a valve, and can be switched between single/double use. The tanks are actually used. Capacity 30000L.
Stainless steel guardrails, solar LED lighting，Developed a new function, the automatic discharge valve, which can directly discharge the liquid after cleaning the tank, and added a visual flange to observe the flow direction of the liquid at any time
DESEINOR complies with UL142 manufacturing standards and has complete design solutions. We have delivered multiple projects of mobile fuel stations and container‑type fuel stations for customers worldwide.Equipped with dual fire extinguishers, smoke alarm system, explosion-proof lighting，The operating system is explosion-proof to close and open, set parameters, and the tank is made of 8MM standard Q235 material, in line with UL certification standards. Dual machines, 4 fuel nozzles, 50-75L per minute refueling options are available，Equipped with a 10-meter reel and retractor to facilitate remote refueling
Explosion-proof liquid level system, expandable APP port development, liquid high and low level display and alarm light flashing, liquid level synchronization when refueling, data recording, network connection to the device, dual bins and dual displays, English, Arabic and other languages can be set.
Product Name | 30000L mobile fuel station | Application | Fuel Station |
Model Number | 30000L | Kind | Fuel-servicing Equipment |
Material | Q235 | Emergency pressure relief | 21-35kPa |
Surface Treatment | Epoxy zinc-rich primer + epoxy mica intermediate coat + polyurethane topcoat | temperature range | -40℃~+70℃ |
Brand Name | DESEINOR | Max Power | 8Kw or 14Kw |
Working Voltage | 220V/380V | Conditions | New |
Relevant standard | UL142 tank standard design and manufacturing | Installation Method | Parallel Placement |
Packing Size | |||
L*W*H(CM) | 836*290*320 | ||
QTY/CTN | 1 | ||
N.W(KGS) | 11900KGS | ||
