Premium fuel dispenser hose coupler with anti-static, IP65 leakproof design. 3/4" & 1" sizes, high-strength alloy, compatible with gasoline diesel. Durable swivel connector for gas station & mobile refueling use.
DESEINOR fuel dispenser hose coupler, also known as fixed or swivel hose coupling, is a core connecting part for fuel dispensing systems. It is professionally designed to connect fuel nozzles, dispensers and delivery hoses, delivering stable mechanical connection and tight sealing during fuel transmission.
Widely applicable to gas stations, tank trucks and mobile refueling equipment, this coupler fits gasoline, diesel, methanol and other common hydrocarbon fuels. Adopting high-strength alloy and precision processing with chrome/zinc plated surface, it features outstanding anti-corrosion, anti-impact and conductive properties to prevent static accumulation. Built-in leak-proof seals and mechanical locking structure ensure zero dripping and loosening under high pressure and frequent use for long-term safe refueling.
Product Name | Fuel dispenser hose swivel | Application | Fuel Dispenser Accessaries |
Model Number | GY-411C | Kind | coupling |
Material | Zinc and brass | Thread Type | BSP/NPT |
Nominal Diameter | 3/4” and 1” | Rotatable angle | 360° |
Brand Name | DESEINOR | Resistance | ≤10Ω |
Sealing Grade | IP65 | Installation Method | Thread |
Temperature | -30℃-80℃ | Applicable Media | Diesel, gasoline, kerosene, methanol, etc. |
3/4 inch Packing Size | |||
L*W*H(CM) | 5*6*13 | ||
QTY/CTN | 1PCS/Box | ||
N.W(KGS) | 0.3KGS | ||
Product Advantages
Safe & Reliable: Anti-static conductive design eliminates static spark risks; dual O-ring and face seal structure achieves full leakage prevention for safe fuel delivery.
Durable & Wear-resistant: High-strength alloy body resists impact and torsion; premium plating enhances corrosion resistance, adapting to frequent daily operation of gas stations.
Easy Installation: Standard universal threaded interfaces support fast assembly and disassembly without special tools, compatible with ZVA, OPW and other mainstream brand nozzles and dispensers.
Wide Compatibility: 3/4" and 1" dual sizes optional, supporting 360° swivel anti-tangle and fixed connection modes to meet diverse usage needs.
Standard Compliant: Fully conforms to gas station emission and fuel system safety standards, available with OIML metrology certification.
4. Application Scenarios
Fuel dispenser and nozzle pipeline connection for gas stations
Quick hose connection for tank truck unloading ports
Pipeline supporting for mobile refueling units and skid-mounted refueling equipment
Transition connection for various fuel delivery pipelines
5. Installation & Usage Notes
Clean thread surfaces thoroughly before installation, and apply appropriate sealant or PTFE tape to avoid leakage and thread damage.
Do not operate under overpressure, overtemperature conditions or contact with strong corrosive media.
Inspect sealing parts regularly and replace aging or cracked seals timely to ensure sealing performance.
Avoid severe impact during handling and installation to prevent body deformation and sealing failure.
