GY412A50 fuel dispenser sealing joint connects RMC & IMC conduit, vertical & horizontal mounting with 40% wire fill rate. Blocks gas leakage, flame spread and explosion risk for flammable gas, dust hazardous fuel equipment sites.
GY412A50 Fuel Dispenser Sealing Joint are used to connect RMC (Rigid Metal Conduit) and IMC (Intermediate Metal Conduit). They can be installed vertically or horizontally. The filling rate is 40%, and the filling amount of wires in the fitting should not exceed this value to ensure the sealing effect.
These fittings can seal the wires inside the conduits, minimizing the leakage of gases and vapors, preventing flames from spreading from one electrical device to another, confining explosions within the sealed conduits, and preventing pressure accumulation in the conduit system. They are suitable for hazardous locations where flammable gases, vapors, metal powders, or dust are present.
Product Name | Fuel dispenser sealing joint | Application | Fuel Dispenser Accessaries |
Model Number | GY412A50 | Kind | Fuel Station Accessaries |
Material | Cast Steel | Surface Treatment | Polishing |
Nominal Size | 2” | Working Temperature | -40℃~+70℃ |
Brand Name | DESEINOR | Catheter direction | Horizontal/Vertical |
Place of Origin | China | Installation Method | Thread |
Thread Type | NPT/BSP | relevant standard |
CSA C22.2 No 30 |
Packing Size | |||
L*W*H(CM) | 17*10.5*7 | ||
QTY/CTN | 1PCS/Box | ||
N.W(KGS) | 0.9KGS | ||
